24 AWG, Multi-conductor Electronic Cable, 12 Conductor, Unshielded, Red83512
IEWC Part #: 2412CSS-1BEE
Manf. Part #:83512 0021000
Manufacturer:Belden
Expected Country of Origin:US
24 AWG stranded (7x32) TC conductors, conductors cabled, plenum, FEP insulated, overall Beldfoil® (100% coverage) + TC braid shield plus (85% coverage), FEP jacket.
Add to cart to request quote
FT
Gauge Size 24 Specification(s) NEC CMP # of Conductors 12 Color RED Voltage 300V Temperature 200C Overall Shielding Type ALUMINUM FOIL/POLYESTER TAPE AND TINNED COPPER BRAID Jacket Material FEP Stranding 7 Conductor Metal TINNED COPPER Insulation Material FEP Conductor Type STRANDED # of Pairs 0 Armor Type NONE Conductor Configuration CONDUCTORS Conductor Shielding Type UNSHIELDED Label Type UL CUL Manufacturer Belden Supplier Series 83512 UL Type CMP Customers can return standard, non-serviced IEWC products (the "Products") as follows:
